3 kWh home kit at 110 V with Growatt 3000W 48V inverter charger and 5 kwh battery

SKU: S3KW_GROW-2-1 Categories: , , , , ,
Photovoltaic kit designed to support installations of up to 3 KW demand
with a 110 V voltage inverter, designed to charge the batteries using
photovoltaic solar energy and/or the electrical grid.
This kit supports growth in demand capacity and or to provide 220V
capacity.
Designed for people who want to make an initial investment and then
grow their system.

CUP: $1,666,561.00

1 in stock

Description

Solar Kit Components List

1. Solar Generation

  • Solar Panels: 5 × HiMAX5 550W Monocrystalline PERC Photovoltaic Panels (Total: 2.75 kWp)

  • Mounting Structure: 1 × MG Solar 20-degree tilt rack for 6 panels (allows for future expansion)

  • PV Wiring:

    • 20m (65.6 ft) 12 AWG PV Cable (2000V, black)

    • 20m (65.6 ft) 12 AWG PV Cable (2000V, red)

    • 2 × MC4 Connector Pairs

2. Energy Storage

  • 1 × LUX-E-48100LG04 Lithium Battery:

    • Capacity: 5kWh

    • Voltage: 48-51.2V (compatible with 48V systems)

3. Power Conversion & Management

  • 1 × Growatt LVM-ES SPF 3000TL Hybrid Inverter:

    • 3kW continuous power output

    • 120V AC output

    • Solar input voltage range: 120-250V DC

    • 48V battery compatibility

4. Electrical Protection

  • DC Side Protection:

    • 1 × 63A 2-Pole DC Miniature Circuit Breaker (500V DC)

    • 2 × 15A Fuses with holders

  • AC Side Protection:

    • 2 × 1P 32A 400V Circuit Breakers (6kA rating)

  • Safety Disconnect:

    • 1 × 3-Pole 63A Knife Switch (Double Copper Contact)

5. Additional Components

  • 20m (65.6 ft) 10 AWG black cable

  • 1 × 8-module wall-mounted enclosure (white)

Key Features Summary

✔ 2.75 kW solar array (5 × 550W high-efficiency panels)
✔ 5kWh lithium battery bank (48V system with voltage range 48-51.2V)
✔ 3kW hybrid in

verter (Growatt with 120V output)
✔ Complete protection system (DC/AC breakers, fuses, disconnect switch)
✔ Expandable design (6-panel rack for future additions)

Note: The system now features a single 5kWh lithium battery instead of the previous 4 × 12V 100Ah LiFePO4 batteries, providing a more compact and integrated storage solution while maintaining the same 48V system voltage.


Technical Data Sheet Talesun PV Panels 540W Bifacial Dual Glass
GROWATT LVM-ES SPF 3000TL 3kW 120V Technical Data Sheet
Lithium Battery LUX-E-48100LG04 Capacity: 5kwh
Installation service: 81,000.00 CUP
Note: The service does not include transportation, lodging and food costs for staff in case of transfers outside the province.
 If any extra material is necessary for installation, it will be agreed with the client on site.
