6 KWh split-phase 110/220V kit with 6000W 48V MPP Solar inverter with 15 kwh battery

Categories: , , , , , , , ,
Photovoltaic kit designed to support installations of up to 6 KW demand with SUN WP6000 split-phase
inverter at 110/220 V voltage. Designed to charge batteries using photovoltaic solar energy and/or
the electrical grid. This kit allows the connection of 220V equipment such as air conditioners and splits.
It does not have the capacity for further growth.

CUP: $3,546,366.34

Description

This kit consists of:

EQUIPMENT UNIT QUANTITY
HiMAX5 550W Monocrystalline PERC Photovoltaic Solar Panel,                          U            12
MG Solar 20-degree Six-panel Frame,                                                                          U             2
Lithium Battery LUX-Y-48300LG01 Capacity: 15kWh Voltage: 48V ~ 51.2V,     U             1
12 AWG 2000V Black PV Photovoltaic Cable,                                                             mts         20
12 AWG 2000V Red PV Photovoltaic Cable,                                                                mts         20
Fuse Holder,                                                                                                                        U             2
15A Fuse,                                                                                                                              U             2
DC 2-pole 63 Ampere Miniature Circuit Breaker, 500V DC,                                    U             1
6AWG Cable,                                                                                                                      mts         30
MC4 Connector,                                                                                                                Pairs        4
ANL-150A Fuse,                                                                                                                  U            2
SGL8N-2 Circuit Breaker DC disconnect 2P 1000V 250A                                        U            1
4 AWG copper cable, maximum current 150 A                                                            U            6
4 x 5/16 tinned copper connectors, 4 AWG                                                                  U            16
SCB8-63 AC MCB Circuit Breaker 2P 40A 6kA 400V                                                U            2
White surface-mounted panel for 8 modules                                                               U            1
63A double-contact copper knife switch, 3 pole                                                          U             1
MPP SOLAR INVERTER LVX6048 (6KW 48V)                                                         U             1




Installation service               94,500.00
Technical Data Sheet Talesun PV Panels 540W Bifacial Dual Glass
SUN 6000W 48V inverter technical sheet
Lithium Battery LUX-Y-48300LG01 Capacity: 15kwh Voltage: 48V ~ 51.2V
Note: The service does not include transportation, lodging and food expenses for staff in case of transfers outside the province. Nor are the auxiliary materials necessary to adapt the kit to the configuration of the home included:
cable, gutters, pipes and accessories, which will be agreed upon with the client at the time of signing the contract.
